CO4x+ Coastal Quad

Our Boats  /  Coastal  /  CO4x+ Coastal Quad

Overview

The CO4x+ is the most versatile coastal quad on the market. The boat runs beautifully and does not stop when going through waves. The hull is designed to excel in surfing and to perform in flatwater too. This boat is incredible at turning due to its well-designed rudder system and back-half hull shape.

The reverse-design riggers have four fixing points and a short outboard: very efficient, while also allowing for quick derigging for compact storage at boat houses.

This boat has won five out of six medals at the 2023 WRCC, for a total of 22 World Championship medals across 5 World Championships in flat and wavy conditions. The boat has set records at long-distance races such as the San Remo to Monaco 32 km race and Hong Kong's 'Around the Island' Race.

Designed for 4 scullers plus coxswain, the C402C hull offers a 10.7 m length with excellent stability for crew coordination in challenging conditions.

Specifications

Mould # C402C+
Boat type 4x/+
Crew weight (kg) 65-95
Crew weight (lb) 143-209
Length (cm) 1069

For CO2x, CO4x, fold-in riggers.

From July 2024 we have kept the same standard work height as before, but without using spacers. Using the spacers provided will increase work height by 10 mm.

As with all our boats, we can build custom riggers, ask your distributor for detail.

Boat Grades & Construction

Each grade is finished to the same high standard, with a different price point, and may be more suitable for certain situations and environments.

All Swift racing shells share these core features:

  1. "Sandwich" construction (ie. A core material such as honeycomb, coremat, or PVC foam is sandwiched between 2 "skins").
  2. Epoxy resin, cured at high temperature, under vacuum.
  3. Enclosed seat decks for maximum buoyancy (exceed FISA's requirement).

With various grades, you can choose the materials and price which best suits your needs, whether that is rowing in the Olympics or putting out a fleet of robust singles for your Novice Masters group.

:: Carbon Pro - (since 2023)

OverviewFor when every second counts.
Hull & SaxboardsHoneycomb core with inner and outer skin of prepreg carbon, and prepreg carbon reinforcing.
Canvas Decks & Seat DeckHoneycomb core with inner and outer skin of prepreg carbon.

:: Elite Carbon

OverviewFor use in top level competition.
Hull & SaxboardsHoneycomb core with inner and outer skin of carbon, and carbon reinforcing.
Canvas DecksHoneycomb core with inner skin of prepreg carbon, outer skin of carbon.
Seat DeckClosed cell PVC foam core with carbon skins.

:: Elite Plus

OverviewFor use in top level competition.
HullHoneycomb core with inner skin of mostly prepreg carbon for 2s, 4s and 8s; carbon for 1s. Outer skin of prepreg K&C for 2s, 4s and 8s; carbon for 1s.
SaxboardsHoneycomb core with inner skin of prepreg carbon, outer skin of prepreg K&C, and prepreg carbon reinforcing.
Canvas DecksHoneycomb core with prepreg carbon skins.
Seat DeckClosed cell PVC foam core with inner and outer skin of prepreg carbon.

:: Club A

OverviewMainly for training purposes, although with only a small weight disadvantage over Elite Plus boats, can still be highly competitive.
HullCoremat core with inner skin of carbon and outer skin of kevlar, and carbon reinforcing.
SaxboardsHoneycomb core for 2s, 4s and 8s, closed cell PVC foam for 1s, with carbon and kevlar skins, and carbon reinforcing.
Canvas DecksHoneycomb core with Prepreg FG skins.
Seat DeckClosed cell PVC foam core with carbon and kevlar skins.

:: Club B

OverviewSpecifically built for training purposes. Quite heavy, but great "work horses". This construction is relatively easy to repair.
HullCoremat core with fibreglass skins.
SaxboardsHoneycomb core for 2s, 4s and 8s, closed cell foam for 1s, with fibreglass skins, and carbon reinforcing.
Canvas DecksHoneycomb core with Prepreg FG skins.
Seat DeckClosed cell PVC foam core with fibreglass skins.
